EX800ST Wireless Android-based Smart Projector for Business | 3300lm, XGA
Wireless Android-based Smart Projector for Business | 3300lm, XGA
- Convenience made easier through wireless connections, built-in business apps, and over-the-air firmware updates.
- Wireless projector with internet connectivity and USB reading to easily show your ideas during huddle sessions.
- Wireless projector with internet connectivity and USB reading to easily show your ideas during huddle sessions
EX800ST Wireless Android-based Smart Projector for Business | 3300lm, XGA
Wireless Android-based Smart Projector for Business | 3300lm, XGA
- Convenience made easier through wireless connections, built-in business apps, and over-the-air firmware updates.
- Wireless projector with internet connectivity and USB reading to easily show your ideas during huddle sessions.
- Wireless projector with internet connectivity and USB reading to easily show your ideas during huddle sessions
All Specifications
Optical
Throw Ratio
0.61
Zoom Ratio
Fixed
Lens Control
Manual Focus
Keystone Correction
1D, Vertical ± 30 degrees
Projection Size
60"~120"
Projection Offset
115±2.5%( (Full-Height)
Lens shift
N/A
Projection System
DLP Single 0.55" XGA
DMD type
DC3 DMD chip
Brightness
3,300 Lumens
Contrast Ratio*
20,000:1
Display Color
1.07 Billion Colors
Aspect Ratio
Native 4:3 (5 aspect ratio selectable)
Light Source
Lamp 200W
Native Resolution
1024 x 768 pixels, 4:3
Light Source life*
Normal 5000 hrs;Economic 10000 hrs;SmartEco 10000 hrs;LampSave 15000 hrs
Built-in Speaker
2W x1
Security
Security Bar, Kensington anti-theft lock slot
Feature
Built-In smart system, BenQ Launcher, Hidden Wireless dingle, Bluetooth Audio out, HID Devices supported (e.g. Mouse, keyboard) Digital zoom(2x), Digital Shrink(0.8x) and Shift, LAN Control, AMX/ PJ Link/Crestron/MDA,DMS Local Compatibility, FW upgrade via LAN
HDMI
x 1
PC (D-sub 15pin)
x 1
Monitor out (D-sub 15pin,Female)
x 1
Audio in(mini jack)
x 1
Audio out (mini jack)
x 1
RS232 In (D-sub 9pin, male)
x 1
USB TypeA-1
x 1
USB TypeA-2 (5V,1.5A)
x 1
USB Type mini B
x 1
IR Receiver(Front+Top)
x 2
LAN Port(RJ45 for Network )
x 1
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200)
Horizontal Frequency
15~102 KHz
Vertical Scan Rate
23 ~ 120 Hz
HDTV Compatibility
480i, 480p, 576i, 567p, 720p, 1080i, 1080p
Video Compatibility
NTSC, PAL, SECAM
Power Comsumption(Max/Normal/Eco)
Max 320W. Normal 280 W. Eco 235 W.
Standby Power Comsumption
Normal < 0.5Watts. Network < 2W.
Product Dimensions (WxHxD)
296x 120x 250 mm
Product Weight
2.6 Kg+/- 200g
Noise Level(Normal/Eco)
33/29 dBA
Operating Temperature
0 ~ 40oC
Accessories (Standard)
Wireless Dongle: WDR02U Power Cord (by region) Remote Control w/ Battery (RCI023) VGA cable Warranty Card (by region) QSG
Accessories (Optional)
Spare Lamp Kit (5J.JLR05.001) 3D Glasses (5J.J9H25.002) Wall mount (WM06G3) Carry Bag
Power Supply
100 ~ 240V AC
OS System
Android 6.0
ROM/RAM
16GB/2GB
Wireless
Dual Band 802.11ac/b/g/n, 2.4G/5G
Bluetooth
4.0
On Screen Display /Launcher Language
Arabic/Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/Thai/TraditionalChinese/Vietnamese /Farsi (30 Languages)
