- 5,000 ASML and above WUXGA
- 5,000 ASML and above 4K
All Specifications
| Display | ||||||
|---|---|---|---|---|---|---|
|
Brightness (ANSI lumens)
10000
|
Brightness (ANSI lumens)
7000
|
Brightness (ANSI lumens)
5000
|
Brightness (ANSI lumens)
6000
|
Brightness (ANSI lumens)
5500
|
Brightness (ANSI lumens)
5500
|
Brightness (ANSI lumens)
5200
|
|
Resolution
WUXGA (1920x1200)
|
Resolution
WUXGA (1920x1200)
|
Resolution
WUXGA (1920x1200)
|
Resolution
WUXGA (1920x1200)
|
Resolution
WUXGA (1920x1200)
|
Resolution
WUXGA (1920x1200)
|
Resolution
WUXGA (1920x1200)
|
|
Native Aspect Ratio
16:10
|
Native Aspect Ratio
16:10
|
Native Aspect Ratio
16:10
|
Native Aspect Ratio
16:10
|
Native Aspect Ratio
16:10
|
Native Aspect Ratio
16:10
|
Native Aspect Ratio
16:10
|
|
Contrast Ratio (FOFO)
3,000,000:1
|
Contrast Ratio (FOFO)
3,000,000:1
|
Contrast Ratio (FOFO)
3000000:1
|
Contrast Ratio (FOFO)
3,000,000:1
|
Contrast Ratio (FOFO)
3,000,000:1
|
Contrast Ratio (FOFO)
3,000,000:1
|
Contrast Ratio (FOFO)
3,000,000:1
|
|
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
Display Color
30 Bits (1,07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
|
Light Source
Laser
|
Light Source
Laser
|
Light Source
Laser
|
Light Source
Laser
|
Light Source
Laser
|
Light Source
Laser
|
Light Source
Laser
|
|
Light Source Life
a. Normal 20000 hrs, b. ECO 38000 hrs, d. Dimming 70000 hrs
|
Light Source Life
a. Normal 20000 hrs, b. ECO 38000 hrs, d. Dimming 75000 hrs
|
Light Source Life
20000 hrs
|
Light Source Life
20000 hrs
|
Light Source Life
20000 hrs
|
Light Source Life
a. Normal 20000 hrs, b. ECO 38000 hrs, d. Dimming 70000 hrs
|
Light Source Life
a. Normal 20000 hrs, b. ECO 38000 hrs, d. Dimming 70000 hrs
|
| Optical | ||||||
|
Throw Ratio
(Optional Lens) Ultra Short Throw: 0.38 LS1ST3A Short throw 0.77-1.1 LS1ST2A Wide Zoom 2: 1.1-1.3 LS1ST1A Wide Zoom 1: 1.25-1.6 LS1SDA Standard: 1.54-1.93 LS1LT0 Semi long: 1.93-2.9 LS1LT1 Semi long 1: 2.22-3.67 LS1LT2 Long zoom 1: 3.58-5.38 LS1LT3 Long Zoom2: 5.31~8.26
|
Throw Ratio
(Optional Lens)Wide Fix: 0.77Wide Zoom: 1.1~1.3Standard: 1.54~1.93Semi Long: 1.93~2.9Long Zoom1: 3.0~5.0 Short Throw:0.77~1.1 SemiThrow:1.25~1.6
|
Throw Ratio
1.36 ~ 2.18
|
Throw Ratio
1.36-2.18
|
Throw Ratio
0.81 ~ 0.89
|
Throw Ratio
0.77-0.84
|
Throw Ratio
.0.5
|
|
Zoom Ratio
(Optional Lens) Long Zoom 1: 1.5x, (Optional Lens) Long Zoom 1: 1.67x, (Optional Lens) Semi Long: 1.5x, (Optional Lens) Semi Long: 1.65x, (Optional Lens) Semi Throw: 1.28x, (Optional Lens) Standard: 1.25x, (Optional Lens) Ultra Short Throw: Fixed, (Optional Lens) Ultra Wide: 1.25x, (Optional Lens) Wide Zoom: 1.18x
|
Zoom Ratio
(Optional Lens) Long Zoom 1: 1.67x, (Optional Lens) Semi Long: 1.5x, (Optional Lens) Semi Throw: 1.28x, (Optional Lens) Short Throw: 1.42x, (Optional Lens) Standard: 1.25x, (Optional Lens) Wide Fix: Fixed, (Optional Lens) Wide Zoom: 1.18x
|
Zoom Ratio
1.6x
|
Zoom Ratio
1.6x
|
Zoom Ratio
1.1x
|
Zoom Ratio
1.1x
|
Zoom Ratio
Fixed
|
|
Lens
LS1ST4 Ultra Short Throw (5J.JCY37.001)
LS1ST3A Short throw (5J.JPN37.001)
LS1ST2A Wide Zoom 2 (5J.JPN37.002)
LS1ST1A Wide Zoom 1 (5J.JPN37.003)
LS1SDA Standard (5J.JPN37.004)
LS1LT0 Semi long (5J.JPN37.005)
LS1LT1 Semi long 1 (5J.JAM37.051)
LS1LT2 Long zoom 1 (5J.JAM37.031)
LS1LT3 Long Zoom2 (5J.JAM37.041)
|
Lens
(Optional Lens)Wide Fix: F=2.5Wide Zoom: F-2.05-2.27Standard: F=2.46-2.56 Semi Long: F=2.5-3.1Long Zoom1: F=2.2-2.5 Short Throw:F=2.05-2.27 Semi Throw: F=2.00-2.24
|
Lens
F/# = 1.81 ~ 2.1,f = 14.3 ~ 22.9 mm
|
Lens
F/# = 1.81 ~ 2.1,f = 14.3 ~ 22.9 mm
|
Lens
F/# = 1.83 ~ 1.86,f = 8.6 ~ 9.4 mm
|
Lens
F/# = 1.9 ~ 1.954,f = 8.14 ~ 8.921 mm
|
Lens
Manual
|
|
Projection Offset (Full-Height)
0%
|
Projection Offset (Full-Height)
0%
|
Projection Offset (Full-Height)
0%
|
Projection Offset (Full-Height)
0%
|
Projection Offset (Full-Height)
0%
|
Projection Offset (Full-Height)
0%
|
Projection Offset (Full-Height)
0%
|
|
Keystone Adjustment
2D, Vertical ± 30 degrees; Horizontal ± 30 degrees
|
Keystone Adjustment
2D, Vertical ± 30 degrees; Horizontal ± 30 degrees
|
Keystone Adjustment
2D, Vertical ± 30 degrees; Horizontal ± 30 degrees
|
Keystone Adjustment
2D, Vertical ± 30 degrees; Horizontal ± 30 degrees
|
Keystone Adjustment
2D, Vertical ± 30 degrees; Horizontal ± 30 degrees
|
Keystone Adjustment
2D, Vertical ± 30 degrees; Horizontal ± 30 degrees
|
Keystone Adjustment
2D, Vertical ± 30 degrees; Horizontal ± 30 degrees
|
|
Lens Shift Vertical
(Optional Lens)Ultra Short Throw: V: (-3% ~ +7%) H: (-5%- 5%) LS1ST3A Short throw: '-15 ~ +55% Vertical; -5% ~ +5% Horizontal LS1ST2A Wide Zoom 2 '-15 ~ +55% Vertical; -5% ~ +5% Horizontal LS1ST1A Wide Zoom 1: '-15 ~ +55% Vertical; -5% ~ +5% Horizontal LS1SDA Standard '-15 ~ +55% Vertical; -5% ~ +5% Horizontal LS1LT0 Semi long (5J.JPN37.005) '-15 ~ +55% Vertical; -5% ~ +5% Horizontal LS1LT1 Semi long 1 0 ~ +50% Vertical; -10% ~ +10% Horizontal LS1LT2 Long zoom 1: 0 ~ +50% Vertical; -10% ~ +10% Horizontal LS1LT3 Long Zoom2: 0 ~ +50% Vertical; -10% ~ +10% Horizontal
|
Lens Shift Vertical
(Optional Lens)Fixed Short Throw: V (-15%~55%+) / H (+- 5%)Standard Short Throw:V (-15%~55%+) / H (+- 5%)Standard Lens:V (-15%~55%+) / H (+- 5%)Long Throw:V (-15%~55%+) / H (+- 5%)Super Long Throw:V (-15%~55%+) / H (+- 5%) Short Throw:V (-15%~55%+) / H (+- 5%)
Semi Throw: V (-15%~55%+) / H (+- 5%)
|
Lens Shift Vertical
± 60%
|
Lens Shift Vertical
-60%~ +60%
|
Lens Shift Vertical
Vertical: -60%~ +60%
Horiztonal : -23%~ +23%
|
Lens Shift Vertical
-62%~ +62%
|
Lens Shift Vertical
-55%~ +55%
|
|
Lens Shift Horizontal
|
Lens Shift Horizontal
|
Lens Shift Horizontal
± 23%
|
Lens Shift Horizontal
-23%~ +23%
|
Lens Shift Horizontal
|
Lens Shift Horizontal
-24%~ +24%
|
Lens Shift Horizontal
-23%~ +23%
|
| Picture | ||||||
|
Rec. 709 Coverage
95%
|
Rec. 709 Coverage
96%
|
Rec. 709 Coverage
92%
|
Rec. 709 Coverage
92%
|
Rec. 709 Coverage
92%
|
Rec. 709 Coverage
92%
|
Rec. 709 Coverage
92%
|
|
Picture Modes
3D, Bright, DICOM SIM, HDR10, HLG, Infographic, Presentation, sRGB, User 1, User 2, Video
|
Picture Modes
3D, Bright, Cinema, DICOM SIM, HDR, HLG, Presentation, sRGB, User 1, User 2, Vivid
|
Picture Modes
3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Video
|
Picture Modes
3D, Bright, Golf, Infographic, Presentation, sRGB, User 1, User 2, Vivid
|
Picture Modes
3D, Bright, Golf, Presentation, sRGB, User 1, User 2
|
Picture Modes
3D, Bright, DICOM SIM, HDR10, HLG, Presentation, Simulator, sRGB, User 1, User 2, Video
|
Picture Modes
3D, Bright, HDR10, HLG, Presentation, Simulator, sRGB, User 1, User 2, Video
|
| Compatibility | ||||||
|
Input Lag
33.4 ms (1080P 60Hz)
|
Input Lag
33.4 ms (1080P 60Hz)
|
Input Lag
2 frame (33.34ms) 60Hz
|
Input Lag
33.4 ms (1080P 60Hz)
|
Input Lag
33.4 ms (1080p@60Hz)
|
Input Lag
8.3 ms (1080P 120Hz)
|
Input Lag
8.3 ms (1080P 120Hz),
|
|
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
|
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
|
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
|
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
|
|
Horizontal Frequency
15K~135KHz
|
Horizontal Frequency
15K~102KHz
|
Horizontal Frequency
15K~102KHz
|
Horizontal Frequency
15K~102KHz
|
Horizontal Frequency
15K~102KHz
|
Horizontal Frequency
15K~135KHz
|
Horizontal Frequency
15K~135KHz
|
|
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
| I/O Interface | ||||||
|
PC in (D-sub 15pin)
(x1)
|
PC in (D-sub 15pin)
(x1), PC in-2 (shared with component video 5BNC)
|
PC in (D-sub 15pin)
(x1), PC in-1
|
PC in (D-sub 15pin)
(x1), PC in-1
|
PC in (D-sub 15pin)
(x1), PC in-1
|
PC in (D-sub 15pin)
(x1), PC in-1
|
PC in (D-sub 15pin)
(x1), PC in-1
|
|
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
|
Composite Video in (RCA)
|
Composite Video in (RCA)
(x1)
|
Composite Video in (RCA)
(x1)
|
Composite Video in (RCA)
|
Composite Video in (RCA)
|
Composite Video in (RCA)
|
Composite Video in (RCA)
|
|
Component Video in (3RCA)
|
Component Video in (3RCA)
|
Component Video in (3RCA)
(x1)
|
Component Video in (3RCA)
|
Component Video in (3RCA)
|
Component Video in (3RCA)
|
Component Video in (3RCA)
|
|
Component Video in (5BNC)
|
Component Video in (5BNC)
1
|
Component Video in (5BNC)
|
Component Video in (5BNC)
|
Component Video in (5BNC)
|
Component Video in (5BNC)
|
Component Video in (5BNC)
|
|
HDMI in
(x2)
|
HDMI in
(x2), HDMI-1 (2.0a/HDCP2.2), HDMI-2 (2.0a/HDCP2.2)
|
HDMI in
(x2), HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4)
|
HDMI in
(x2), HDMI-1 (2.0a/HDCP2.2), HDMI-2 (2.0a/HDCP2.2)
|
HDMI in
(x2), HDMI-1 (2.0a/HDCP2.2), HDMI-2 (2.0a/HDCP2.2)
|
HDMI in
(x2), HDMI-1 (2.0a/HDCP2.2), HDMI-2 (2.0a/HDCP2.2)
|
HDMI in
(x2), HDMI-1 (2.0a/HDCP2.2), HDMI-2 (2.0a/HDCP2.2)
|
|
Monitor out (HDMI)
|
Monitor out (HDMI)
|
Monitor out (HDMI)
|
Monitor out (HDMI)
|
Monitor out (HDMI)
|
Monitor out (HDMI)
(x1)
|
Monitor out (HDMI)
(x1)
|
|
Display Port
|
Display Port
|
Display Port
|
Display Port
|
Display Port
|
Display Port
(x1)
|
Display Port
(x1)
|
|
LAN (RJ45)
(x1)
|
LAN (RJ45)
(x1)
|
LAN (RJ45)
(x1)
|
LAN (RJ45)
(x1)
|
LAN (RJ45)
(x1)
|
LAN (RJ45)
(x1)
|
LAN (RJ45)
(x1)
|
|
HDBaseT (RJ45)
(x1)
|
HDBaseT (RJ45)
(x1), Control/Video/Audio
|
HDBaseT (RJ45)
|
HDBaseT (RJ45)
(x1), Video/Audio
|
HDBaseT (RJ45)
(x1), Video/Audio
|
HDBaseT (RJ45)
(x1), Control/Video/Audio
|
HDBaseT (RJ45)
(x1), Control/Video/Audio
|
|
3D Sync in
(x1)
|
3D Sync in
(x1)
|
3D Sync in
|
3D Sync in
(x1)
|
3D Sync in
(x1)
|
3D Sync in
(x1)
|
3D Sync in
(x1)
|
|
3D Sync out
(x1)
|
3D Sync out
(x1)
|
3D Sync out
|
3D Sync out
(x1)
|
3D Sync out
(x1)
|
3D Sync out
(x1)
|
3D Sync out
(x1)
|
|
USB Type A
(x1)
|
USB Type A
(x1), USB Type A-1 (2.0/Power Supply1.5A)
|
USB Type A
(x1), USB Type A-1 (2.0/Power Supply1.5A/Service)
|
USB Type A
(x1), USB Type A-1 (2.0/Power Supply1.5A)
|
USB Type A
(x1), USB Type A-1 (2.0/Power Supply1.5A)
|
USB Type A
(x1), USB Type A-1 (2.0/Power Supply1.5A)
|
USB Type A
(x1), USB Type A-1 (2.0/Power Supply1.5A)
|
|
USB Type B
USB Type B-1(service)
|
USB Type B
USB Type B-1(service)
|
USB Type B
|
USB Type B
|
USB Type B
|
USB Type B
|
USB Type B
|
|
USB Type Mini B
|
USB Type Mini B
|
USB Type Mini B
|
USB Type Mini B
|
USB Type Mini B
|
USB Type Mini B
(x1), USB Type Mini B-1(service)
|
USB Type Mini B
(x1), USB Type Mini B-1(service)
|
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
|
RS232 out (DB-9pin)
(x1)
|
RS232 out (DB-9pin)
(x1)
|
RS232 out (DB-9pin)
|
RS232 out (DB-9pin)
|
RS232 out (DB-9pin)
|
RS232 out (DB-9pin)
|
RS232 out (DB-9pin)
|
|
Wired Remote in (3.5mm Mini Jack)
(x1)
|
Wired Remote in (3.5mm Mini Jack)
(x1)
|
Wired Remote in (3.5mm Mini Jack)
|
Wired Remote in (3.5mm Mini Jack)
(x1)
|
Wired Remote in (3.5mm Mini Jack)
(x1)
|
Wired Remote in (3.5mm Mini Jack)
(x1)
|
Wired Remote in (3.5mm Mini Jack)
(x1)
|
|
Wired Remote out (3.5mm Mini Jack)
(x1)
|
Wired Remote out (3.5mm Mini Jack)
(x1)
|
Wired Remote out (3.5mm Mini Jack)
|
Wired Remote out (3.5mm Mini Jack)
|
Wired Remote out (3.5mm Mini Jack)
|
Wired Remote out (3.5mm Mini Jack)
|
Wired Remote out (3.5mm Mini Jack)
|
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
| Audio | ||||||
|
Speaker
No Speaker
|
Speaker
(x2), 10W
|
Speaker
(x2), 10W
|
Speaker
(x2), 10W
|
Speaker
(x2), 10W
|
Speaker
(x1), 10W
|
Speaker
(x1), 10W
|
|
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
(x1), 1
|
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
(x1)
|
|
Audio out (3.5mm Mini Jack)
|
Audio out (3.5mm Mini Jack)
|
Audio out (3.5mm Mini Jack)
(x1), 1
|
Audio out (3.5mm Mini Jack)
(x1)
|
Audio out (3.5mm Mini Jack)
(x1)
|
Audio out (3.5mm Mini Jack)
(x1)
|
Audio out (3.5mm Mini Jack)
(x1)
|
| Environment | ||||||
|
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
|
Typical Power Consumption (110V)
893W
|
Typical Power Consumption (110V)
600
|
Typical Power Consumption (110V)
415
|
Typical Power Consumption (110V)
440W
|
Typical Power Consumption (110V)
440W
|
Typical Power Consumption (110V)
450W
|
Typical Power Consumption (110V)
450W
|
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
|
Network Stand-by Power Consumption
<6W
|
Network Stand-by Power Consumption
<2W
|
Network Stand-by Power Consumption
<2W
|
Network Stand-by Power Consumption
<2W
|
Network Stand-by Power Consumption
<2W
|
Network Stand-by Power Consumption
<2W
|
Network Stand-by Power Consumption
<2W
|
|
Acoustic Noise (Typ./Eco.)(dB)
42/38
|
Acoustic Noise (Typ./Eco.)(dB)
36/34
|
Acoustic Noise (Typ./Eco.)(dB)
|
Acoustic Noise (Typ./Eco.)(dB)
|
Acoustic Noise (Typ./Eco.)(dB)
|
Acoustic Noise (Typ./Eco.)(dB)
|
Acoustic Noise (Typ./Eco.)(dB)
|
| Accessories | ||||||
|
Remote Control w/ Battery
RCA025
|
Remote Control w/ Battery
RCA024
|
Remote Control w/ Battery
RCE016
|
Remote Control w/ Battery
RCA011
|
Remote Control w/ Battery
RCA011
|
Remote Control w/ Battery
RCA024
|
Remote Control w/ Battery
RCA024
|
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
|
VGA(D-sub 15pin) Cable
|
VGA(D-sub 15pin) Cable
1 (1.8m)
|
VGA(D-sub 15pin) Cable
|
VGA(D-sub 15pin) Cable
|
VGA(D-sub 15pin) Cable
|
VGA(D-sub 15pin) Cable
|
VGA(D-sub 15pin) Cable
|
|
HDMI cable
|
HDMI cable
|
HDMI cable
Yes, 1.8m
|
HDMI cable
|
HDMI cable
|
HDMI cable
|
HDMI cable
|
|
User Manual CD
1 (12L)
|
User Manual CD
|
User Manual CD
|
User Manual CD
|
User Manual CD
|
User Manual CD
|
User Manual CD
|
|
3D Glasses
|
3D Glasses
(Optional), DGD5
|
3D Glasses
(Optional), DGD5
|
3D Glasses
(Optional), DGD5
|
3D Glasses
(Optional), DGD5
|
3D Glasses
DGD5, (Optional)
|
3D Glasses
|
|
Quick Start Guide
|
Quick Start Guide
|
Quick Start Guide
1 (21L)
|
Quick Start Guide
|
Quick Start Guide
|
Quick Start Guide
|
Quick Start Guide
|
|
Installation Guide
Yes
|
Installation Guide
Yes
|
Installation Guide
|
Installation Guide
1 (8L)
|
Installation Guide
1 (8L)
|
Installation Guide
1 (8L)
|
Installation Guide
1 (8L)
|
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
|
Lens cover
Yes
|
Lens cover
|
Lens cover
|
Lens cover
|
Lens cover
|
Lens cover
|
Lens cover
|
|
Anti-dust Filter
|
Anti-dust Filter
(Standard), All SKU
|
Anti-dust Filter
(Optional), Yes
|
Anti-dust Filter
|
Anti-dust Filter
|
Anti-dust Filter
|
Anti-dust Filter
|
|
Universal Ceiling Mount
|
Universal Ceiling Mount
(Optional), CM00G6
|
Universal Ceiling Mount
Yes, CMG3
|
Universal Ceiling Mount
(Optional), CM00G3
|
Universal Ceiling Mount
(Optional), CM00G3
|
Universal Ceiling Mount
|
Universal Ceiling Mount
|
| Smart System | ||||||
|
Preload Apps
|
Preload Apps
|
Preload Apps
|
Preload Apps
|
Preload Apps
|
Preload Apps
NA
|
Preload Apps
NA
|
| Dimension & Weight | ||||||
|
Dimensions (WxHxD) (mm)
500 x 211 x 587.3
|
Dimensions (WxHxD) (mm)
525 x216 x470
|
Dimensions (WxHxD) (mm)
416 x166 x351
|
Dimensions (WxHxD) (mm)
416x166 x 351 mm
|
Dimensions (WxHxD) (mm)
416x166 x 351 mm
|
Dimensions (WxHxD) (mm)
479.6 x 182.8 x 402
|
Dimensions (WxHxD) (mm)
479.6 x 182.8 x 402
|
|
Net Weight (kg)
26.8
|
Net Weight (kg)
25
|
Net Weight (kg)
6.3
|
Net Weight (kg)
7
|
Net Weight (kg)
7
|
Net Weight (kg)
12
|
Net Weight (kg)
12
|
|
Dimensions (WxHXD) (inch)
|
Dimensions (WxHXD) (inch)
|
Dimensions (WxHXD) (inch)
|
Dimensions (WxHXD) (inch)
|
Dimensions (WxHXD) (inch)
|
Dimensions (WxHXD) (inch)
18.9 x 7.2 x 15.8
|
Dimensions (WxHXD) (inch)
18.9 x 7.2 x 15.8
|
|
Net Weight (lb)
|
Net Weight (lb)
|
Net Weight (lb)
|
Net Weight (lb)
|
Net Weight (lb)
|
Net Weight (lb)
26.46
|
Net Weight (lb)
26.46
|
| Projection System | ||||||
|
Projection System
DLP
|
Projection System
DLP
|
Projection System
DLP
|
Projection System
DLP
|
Projection System
DLP
|
Projection System
DLP
|
Projection System
DLP
|
All Specifications
| Display | |||
|---|---|---|---|
|
Brightness (ANSI lumens)
5500
|
Brightness (ANSI lumens)
5100
|
||
|
Resolution
4K UHD (3840×2160)
|
Resolution
4K UHD (3840×2160)
|
||
|
Native Aspect Ratio
16:9
|
Native Aspect Ratio
16:9
|
||
|
Contrast Ratio (FOFO)
3,000,000:1
|
Contrast Ratio (FOFO)
3,000,000:1
|
||
|
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
||
|
Light Source
Laser
|
Light Source
Laser
|
||
|
Light Source Life
a. Normal 20000 hrs
|
Light Source Life
a. Normal 20000 hrs
|
||
| Optical | |||
|
Throw Ratio
1.36~2.18
|
Throw Ratio
0.81 ~0.89
|
||
|
Zoom Ratio
1.6x
|
Zoom Ratio
1.1x
|
||
|
Lens
F/# =1.809
f= 8.6 ~ 9.4
|
Lens
F/# =1.83 ~ 1.86
f= 8.6 ~ 9.4
|
||
|
Projection Offset (Full-Height)
0%
|
Projection Offset (Full-Height)
0%
|
||
|
Keystone Adjustment
3D, Vertical ± 30 degrees; Horizontal ± 30 degrees; Rotation ± 30 degrees
|
Keystone Adjustment
3D, Vertical ± 40 degrees; Horizontal ± 40 degrees; Rotation ± 40 degrees
|
||
|
Lens Shift Vertical
-60%~ +60%
|
Lens Shift Vertical
-60%~ +60%
|
||
|
Lens Shift Horizontal
-23%~ +23%
|
Lens Shift Horizontal
-23%~ +23%
|
||
| Picture | |||
|
Rec. 709 Coverage
92%
|
Rec. 709 Coverage
92%
|
||
|
Picture Modes
3D, Bright, DICOM SIM, Golf, Infographic, Presentation, sRGB, User 1, User 2, Video, Video Conference
|
Picture Modes
3D, Bright, DICOM SIM, Golf, Infographic, Presentation, sRGB, User 1, User 2, Video
|
||
| Compatibility | |||
|
Input Lag
33.4 ms (1080P 60Hz)
|
Input Lag
33.4 ms (1080P 60Hz)
|
||
|
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
|
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
|
||
|
Horizontal Frequency
15K~135KHz
|
Horizontal Frequency
15K~135KHz
|
||
|
Vertical Scan Rate
23~240Hz
|
Vertical Scan Rate
23~240Hz
|
||
| I/O Interface | |||
|
HDMI in
(x2), HDMI-1 (2.0b/HDCP2.2), HDMI-2 (2.0b/HDCP2.2)
|
HDMI in
(x2), HDMI-1 (2.0b/HDCP2.2), HDMI-2 (2.0b/HDCP2.2)
|
||
|
Display Port
(x1)
|
Display Port
(x1)
|
||
|
LAN (RJ45)
(x1)
|
LAN (RJ45)
(x1)
|
||
|
HDBaseT (RJ45)
(x1), Video/Audio
|
HDBaseT (RJ45)
(x1), Video/Audio
|
||
|
3D Sync in
(x1), VESA
|
3D Sync in
(x1), VESA
|
||
|
3D Sync out
(x1), VESA
|
3D Sync out
(x1), VESA
|
||
|
USB Type A
(x1), USB Type A-1 (2.0/Power Supply2.0A)
|
USB Type A
(x1), USB Type A-1 (2.0/Power Supply2.0A)
|
||
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
||
|
Wired Remote in (3.5mm Mini Jack)
(x1)
|
Wired Remote in (3.5mm Mini Jack)
(x1)
|
||
|
Wired Remote out (3.5mm Mini Jack)
(x1)
|
Wired Remote out (3.5mm Mini Jack)
(x1)
|
||
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
DC 12V Trigger (3.5mm Jack)
(x1)
|
||
| Audio | |||
|
Speaker
(x1), 10W
|
Speaker
(x1), 10W
|
||
|
Audio out (3.5mm Mini Jack)
(x1)
|
Audio out (3.5mm Mini Jack)
(x1)
|
||
|
HDMI Audio Return
ARC, 5.1 channel
|
HDMI Audio Return
Yes, eARC, Dolby Atmos
|
||
|
S/PDIF
Multi-Channel, RAW
|
S/PDIF
Multi-Channel, RAW
|
||
| Environment | |||
|
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
||
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
||
|
Typical Power Consumption (110V)
440W
|
Typical Power Consumption (110V)
440W
|
||
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
||
|
Network Stand-by Power Consumption
<2W
|
Network Stand-by Power Consumption
<2W
|
||
|
Acoustic Noise (Typ./Eco.)(dB)
40/33
|
Acoustic Noise (Typ./Eco.)(dB)
40/33
|
||
| Accessories | |||
|
Remote Control w/ Battery
RCA011
|
Remote Control w/ Battery
RCA011
|
||
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
||
|
HDMI cable
|
HDMI cable
1.8m
|
||
|
3D Glasses
(Optional), DGD5
|
3D Glasses
DGD5, (Optional)
|
||
|
Installation Guide
Yes
|
Installation Guide
1 (8L)
|
||
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
||
|
Universal Ceiling Mount
(Optional), CM00G3
|
Universal Ceiling Mount
CM00G3, (Optional)
|
||
| Dimension & Weight | |||
|
Dimensions (WxHxD) (mm)
416x166x351
|
Dimensions (WxHxD) (mm)
416x166x351
|
||
|
Net Weight (kg)
7.0
|
Net Weight (kg)
7
|
||
| Projection System | |||
|
Projection System
DLP
|
Projection System
DLP
|
Talk to an expert
